Color Changing RGB 3535 LED Strip Light

    Products Name: FS3535

    Wattage: 12W

    Input Voltage: DC 24V

    LED Type: SMD3535 RGB

    Dimension:None

    PCB Width: None

    CCT:RGB

    CRI:80+/90+/95+

    Lumen Output: None

    Beam Angle: 45°

    IP Rating: IP20/IP65/67/68

    Dimmable:YES

    Cetification:None

PRODUCT DESCRIPTION

Color Changing RGB 3535 LED Strip Light

Color Changing RGB 3535 LED Strip Light

High Brightness Color Changing RGB 3535 150W LED Strip Light is made with 600 units per spool of an incredibly bright 3535 three color LED chip. Using the 3 basic colors of Light, RED, GREEN and BLUE, you can create over 16 million different colors using any of our RGB LED controllers.
Our flexible RGB Led Strip is cuttable every 2 inches (50mm).
Also this LED strip includes high grade double sided 3M tape which makes installation very simple, just peel back the protective strip, place the strip and done!




♦ High-bright 3535 RGB color changing led strip, single row.

♦ DC 24V, Max 24Watts/m

♦ Beam angle:120deg.

♦ White PCB for better color performance.

♦ Double layer 2 or 3 oz pure copper FPCB.

♦ 3M double side tape on backside for easy installation.
♦ 3 years warranty.


Parameters

Item Type

Color Changing RGB 3535 LED strip light

Led ModelFS3535RGB120D-24V
LED Qty120Leds/M
Ra/
CCT(K)

RGB

Dimmensions(mm)5000 * 10 * 2(L * W * H)
Voltage
24V
Power19.2w/m
IP RatingIP20/IP54/IP65/IP67/IP68
Bean Angel120º
CertificationCE/RoHS
Warranty3 Years

LED colors

LED color.jpg

Color & Temperature(K):W:1800/2200/2400/2700/3000/4000/5000/6500 /Red/Green/Blue/Yellow/Amber/Pink/Purple


LED Bin

SDCM>1 ; SDCM>3 or SDCM>5 is optional

LED bin.jpg

CRI

Ra>80/90/95  (Customized for 96- 98 )



PCB Board

* The standard PCB board color is white, there are Red/Blue/Green/Black/Brown/Yellow ect color available

* Double size high quality cooper material, 2Oz,3Oz,4Oz thickness optional

* Customized service, such as print LOGO, company name and other is acceptable.

Single line,Double line or customized
